Multi-drug resistant fecal bacteria (MRF) including Gram-negative Escherichia coli and -positive Enterococcus faecium are of prime concern to food safety and public health [1-4]. This study was performed to test efficacy of a natural antimicrobial, polymeric chitosan-based nanoparticles combined with ZnO to in situ intervention. Herein, we examined the effects of nanoparticles (NPs) of chitosan, ZnO alone and a combination of chitosan and ZnO, (CZNPs) at 1:1 on co-cultured nosocomial MRFs and a wild type (WT) through the minimal inhibitory concentration (MIC) test conform to National Standards, NCCLS. Toward elucidating visually the mechanistic effects of NPs alone and CZNPs on MRF and WT strains, Transmission Electronic Microscopy (TEM) was performed. While chitosan 1 (C1) and 2 (C2) alone with a molecular weight of 3 kDa and 50 kDa, respectively inhibited resistant E. coli strain (E. coli BAA-2471), they were ineffective at a concentration less than 5 mg/mL on either E. faecium strains and the co-cultures. ZnO and chitosan alone did not exhibit optimal effects on MRF strains and cultures alone. However, the MRF co-culture, E. coli BAA-2471 and E. faecium 1449 were completely inhibited by the C1ZNPs with an average minimal MIC of 0.781 mg/mL, and a maximal MIC of 1.302 mg/mL. Synergism of C1ZNPs over C2ZNPs proved to be predominantly inhibitive of MRF over WT co-cultures. Further TEM analyses demonstrated attachment and lysis of MRFs at 16h past treatment. Conclusively, CZNPs inhibit MRF co-cultures and is a promising in vivo intervention agent.



Keywords: Nanotechnology; Multi-drug resistant; Fecal bacteria; Enterococcus faecium; Escherichia coli; Chitosan; Zinc oxide; Synergism.

Currently, some strains of multidrug resistant E. faecium concurrently with E. coli pose a serious level of threat to humans [1-4]. While there are several resistant foodborne pathogens originating from animal gut, some strains of MRFs including Vancomycin Resistant E. faecium (VRE) remain the leading cause of hospital-acquired infections with 10,000 hospitalized cases and 650 deaths each year in the U.S. [5]. Clonal complex 17 (CC17) is now the prime causative of patient urinary tract infections in clinical settings and could further lead to serious complications primarily in patients with long stay in hospitals [6]. Conjointly in this pathogenic spread, E. coli is implicated in millions of extraintestinal infections resulting in more than 100,000 cases of sepsis and 40,000 sepsis-associated deaths [7-9]. Moreover, phenotypic elasticity of these MRF strains mainly E. faecium enable them exchange genes with other pathogens such as Salmonella and Campylobacter genera found in food animals [10-12]. It is also quite possible that resistant MRFs from food animals form a niche in the humans’ gastrointestinal tract leading to a reservoir of resistance [14], consequently, jeopardizing the lives of the most immunocompromised populations [15].



Despite the increasing threat of mutating MRFs [5,16], many strains of E. faecium are useful lactic acid bacteria that have been extensively added in food applications for their fermentative ability and health benefits. Despite their probiotic attributes [13], the considerable ability of some E. faecium strains to mutate in multiple types of environments has made the use of E. faecium as a fermentative strain questionable [15]. Furthermore, the continuous use of the traditional antibiotics has led to the induction of “Super Bugs”, that are unresponsive to a wide range of antibiotics [22, 23]. Enterococcus exhibited the ability to develop resistance to basically every drug used against them [15]. Thus, developing remediation strategies against these multi-drug resistant bacteria remains a major unmet need.



As such, an alternative natural antimicrobial that is nontoxic, sustainable was deemed of prime interest. Chitosan, arguably the most important derivative of chitin, is emerging as a strong, natural antimicrobial that is considered safe for human health [6]. Additionally, chitosan with its exposed –NH2 groups is involved in specific interactions with metals [6] which not only allows chitosan to behave differently from other polysaccharides due to the positive charge on its surface. In a solid state, chitosan is a semicrystalline polymer that is soluble in acidic solutions, however, its solubility depends on the distribution of acetyl groups along its polysaccharide chain and the molecular weight [7]. Chitosans have proven to be effective as an antibacterial against a variety of pathogens namely Gram-negative strains and biofilms [24]. The effectiveness of such antibacterial activity was found in a previous report to be correlated with chitosan’s molecular weight, thus allowing the chitosan biopolymers to be highly effective when compoared to chitosan oligomers, which were significantly smaller [32].



Aside from Chitosan, Zinc oxide (ZnO) is emerging as an effective nanocomponent for its effectiveness against some cancer cells [29] in addition to its potential to mitigate some Gram-positive strains with regard to its selective toxicity [29]. On the other hand, Zinc oxide nanoparticles seem to inhibit or cause bacterial death more efficiently when they are smaller in size but higher in concentration. A smaller size at higher concentrations provides higher specific surface areas and facilitates the penetration of the antimicrobial agent into the bacterial membrane [5].



 A few studies demonstrated antiseptic and chemical attributes of chitosan and ZnO jointly used in cotton fabric in addition to UV protection [30,31], suggesting that a combination of chitosan oligomer and ZnO may provide better anti-septic property compared to either agent alone. However, little is known about the effectiveness of either of these nanoparticles against antibiotic resistant strains and MRFs induced illnesses.



We have been investigating the means of remediation of multi-drug resistant bacteria. Based on the reports that a combination of chitosan and ZnO may lead to better nanoformulations exhibiting anti-bacterial properties, in this study, the anti-bacterial properties of polymeric chitosan-based nanoparticles and/or ZnO was investigated and the results show that very small oligomers of chitosan effectively mitigate MRFs and VRE. Our results for the first time demonstrates that chitosan oligomeric nanoparticles by themselves or in combination with ZnO provide for the effective remediation of MRFs and VRE.



Sample collection and culture conditions The MRF, Gram-negative, E. coli BAA-2471 purchased from ATCC and Gram-positive E. faecium 1449 provided from Moffitt Cancer Center were used as target bacteria for this study. These MRF strains were selected for their broad-spectrum resistance and virulence. Tigecycline was the only available drug effective against these strains. The above isolates were cultured on Tryptic Soy Agar (TSA) and Tryptic Soy Broth (TSB) (Sigma, St. Louis, MO) and incubated at 37oC for 24 hours and maintained at 37°C for 24 hours. Bacterial growth was prepared by adding 100 ul fresh culture having 9.5x108 Colony Forming Units (CFU) on Tryptic Soy Agar (TSA) plates.



The chitosan nanoparticles with three different MWs were provided by Dr. Mohapatra’s lab in College of Pharmacy at USF. The ZnO was purchased from Sigma (Sigma, St. Louis, MO).



Serial Dilution and Plate Counts



Single colonies of E. coli BAA-2471 and E. faecium 1449 were inoculated from TSA plate to 15 mL TSB broth (Sigma, St. Louis, MO), respectively. Each broth culture was incubated at 37°C for 24 hours. A seven times tenfold series dilution was performed by serially diluting 100 μL bacteria broth culture into 900 μL TSB. The 100 uL of each dilution was plated on TSA and incubated at 37oC for 24 hours.



Minimal Inhibitory Concentration (MIC) assays



These overnight bacteria cultures were diluted 1 in 1,000 in fresh TSB or LB. Sterile 96-well plates were loaded with a co-cultured E. coli BAA-2471 and E. faecium 1449 (5×105cfu/mL) and screened against chitosan, ZnO alone and CZNPs at decreasing concentrations by 1:2 dilution to equal a total volume of 100 μL in each of the wells. All assays were performed in triplicate with identical results. Care was taken to not add more than 1.0% (CZNPs) to any well. The plates were incubated at 37°C overnight. The MICs were determined after 24 hours by visual determination of the minimum concentration of compound to inhibit growth. Inhibition of growth was determined by lack of turbidity in the wells.



TEM assay



Routine preparation of bacteria by negative staining would require pelleting the bacteria to rinse them in order to remove growth media protein through rinsing. Exposing unfixed bacteria to high-speed centrifugation could alter damaged surface membrane structure. Aldehydes, typically employed to fix and stabilize bacteria prior to observation in the electron microscope, could not be used to stabilize bacteria, as the aldehydes would crosslink proteins in the growth media to the bacterial surface, obscuring surface damage to the bacterial membranes, if present. A new method of fixing the bacteria in osmium tetroxide prior to pelleting was employed to stabilize the bacterial membranes. Osmium would not crosslink any protein in the culture medium to the bacteria, but would preserve the membrane structure of the bacteria throughout the centrifugation process, allowing rinsing to remove the culture media proteins necessary to prepare the bacteria for TEM, and impart electron density similar to that of uranyl acetate or other negative stains used to observe bacteria in the electron microscope.



 Aliquots of bacteria in growth media were initially fixed in equal volume of 2% osmium tetroxide in distilled water for 10 minutes at 4˚C. Following fixation, the bacteria were rinsed in distilled water and pelleted at 5000RPM for 10 minutes. This rinse step was repeated three times. A proper dilution of bacteria was obtained to yield approximately 2000-3000 bacteria per drop, and one drop of a sample was applied to a carbon-formvar coated copper grid. The grid was allowed to air dry. This procedure was repeated for each sample. Once dry, the grids were observed and photographed in the electron microscope.



​

​

The antimicrobial efficacies of chitosan tested after 24 hours incubation at 37°C are shown in Table 1. The chitosan 1 and 3 was not effective against both E. faecium culture and the co-culture as well as the WT cultures. However, chitosan 1 and 3 showed a significantly inhibitory antimicrobial ability (0.0488 mg/mL) against multidrug resistant E. coli BAA-2471 culture compare to non-effective against WT E. coli MCC 13 culture (Figure 1).



Figure 1. Chitosan particles carrying zinc oxide on the collapsing outer membranes of resistant strains.



The MIC values of ZnO tested after 24 hours incubation at 37°C are shown in Table 1. ZnO exhibited varying MICs against different cultures. According to the results, ZnO was more effective against WT E. coli MCC 13 (7.292 mg/mL) and WT E. faecium ATCC 35667 (0.391 mg/mL) than resistant E. coli BAA-2471 (13.54167 mg/mL)and E. faecium 1449 (3.125 mg/mL), respectively. However, ZnO showed a slightly lower MIC of 5.208 mg/mL against resistant co-culture than the WT co-culture with a MIC of 6.25 mg/mL (Figure 2).



A. Wild type bacteria in contact with zinc oxide particles, showing no adverse effects from exposure to the zinc oxide at 4 hours

B. MRFs including E. coli BAA-2471 and E. faecium 1449 showing adsorbed chitosan on their cell membranes. The resistant bacteria have begun to lyse and collapse.



Figure 2. Effects of CZNPS on MRFs compared to wild type control exposure (A, B)



The antimicrobial efficacies of synergism of chitosan and ZnO tested after 24 and 48 hours incubation at 37°C are shown in Table 1. Both C1ZNPs and C2ZNPs presented markedly higher antimicrobial efficacy against resistant co-cultures than WT co- cultures with a minimal average MIC of 0.781 compared to 2.083 mg/mL, respectively. Furthermore, the effectiveness of the CZNPs complex was closely related to the molecular weight of chitosan. Indeed, the MIC values of C1ZNPs against resistant E.coli BAA-2471, E. faecium 1449 and co-culture were 0.0488, 1.563 and 0.781 mg/mL, respectively. However, the MIC values of C2ZNPs against resistant E.coli BAA-2471, E. faecium 1449 and co-culture were 0.0488, 1.042 and 1.302 mg/mL, respectively. Interesting, C1ZNPs with low MW (3 KDa) was much more effective than C2ZNPs with high MW (50 KDa) against resistant co-culture. The MW was one of key factors of NPs to impact the antimicrobial efficacy against bacteria cultures (Figure 3).



A. E. coli BAA-2471 exposed to zinc oxide nanoparticles and chitosan for 16 hours. The bacterium on the left shows chitosan adsorbed to the cell membrane and zinc oxide nanoparticles attached to the membrane. Low electron density indicates that the bacterium is lysing. An intact E. coli BAA-2471 is on the right.

B. E. coli BAA-2471 exposed to chitosan and zinc oxide nanoparticles, showing adsorption of chitosan to cell membrane of bacteria and adherence of zinc oxide to bacteria. ZnO is causing pitting of the bacterial membrane.

C. E. faecium1449 exposed to chitosan and zinc oxide. An intact E. faecium 1449 is in the lower left. Small high-density regions inside the cell are indicative of the nanoparticles. Presence of asterisk-like fragments detail lyses and disintegration of the cell wall.

D. Higher magnification photograph of the disintegration of the cell wall of E. faecium.

E. Resistant co-culture, MRF of E. faecium 1449 and E. coli BAA-2471 subjected to the combinatory nanoparticles. Nanoparticles surrounding the outside of the cells demonstrate clearly the formation of a synergistically formed meshing. Lower electron density indicates lyses of the bacteria, which is noticeable in both bacterial strains though notably more so on E. coli BAA-2471 in this panel.

F. Higher magnification photo of the co-cultured MRFs detailing the presence of nanoparticles surrounding and inside both bacterial species.



Figure 3. Effects of C1ZNPS on resistant E. coli BAA-2471 and E. faecium 1449 alone and co-cultured after 16 hours exposure (Figures B, D, and F present the mechanism effects of C1ZNPs under higher magnification photograph. (A-F)



The antimicrobial efficacies of chitosan tested after 24 hours incubation at 37°C are shown in Table 1. The chitosan 1 and 3 was not effective against both E. faecium culture and the co-culture as well as their WT cultures. However, chitosan 1 and 3 showed a significantly inhibitory antimicrobial ability (0.0488 mg/mL) against multidrug resistant E. coli BAA-2471 culture compare to non-effective against WT E. coli MCC 13 culture.



The minimal inhibitory concentration (MIC) values of the antimicrobials tested after 24 hours incubation at 37°C are shown in Table 1. Zinc oxide and chitosan were tested alone and in equal combined level (1:1) against separate cultures and co-cultures of E. coli strain ATCC BAA-2471 and E. faecium strain 1449. Chitosan 1, and 2, which vary in molecular weights (3 and 50 kDa, respectively) were ineffective at low concentrations (<5%) against either strains of bacteria as well as against the co-culture.





Antimicrobials	Strains of MRFs and Wild Type Counterparts
	Escherichia coli BAA-2471	Escherichia coli MCC 13 (WT)	Entercoccus faecium 1449	Entercoccus faecium ATCC 35667(WT)	Co-culture of BAA-2471 and 1449	Co-culture of MCC 13 and ATCC 35667(WT)
MIC: mg/mL
Chitosan 1 (3 kDA)	<0.0488	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)
Chitosan 2 (50 kDA)	0.04883	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)	Not Detected (>50)
ZnO	13.54167	7.292	3.125	0.391	5.208	6.25
C1ZNPS	<0.0488	2.604	1.563	3.125	0.781	2.083
C2ZNPS	<0.0488	2.083	1.042	2.604	1.302	3.125



Table 1. Minimum Inhibitory Concentration (MIC) values of Chitosan and ZnO against E. faecium and E. coli.



Notes:



^aValues are mean of three replicates.



^bCZNPS: Chitosan combined with Zinc monoxide Nanoparticles.



^cChitosan: C1, C2 with different Molecular Weights of 3kDa and 50 kDa, respectively.



^dND: not detected.



^eCo-cultured MRFs: multidrug resistant E. coli BAA-2471 combined with E. faecium 1449.



^fWT: wild type.



Zinc oxide only had relative effectiveness against E. faecium at a concentration of 3.125 mg/mL. Zinc oxide effectiveness at low concentrations against E. coli or against the co-culture was not detectible. Further tests can confirm if the co-cultures treated with zinc oxide inhibited only the growth of E. faecium or if both microbes grew relatively unhindered. The values denoted for combinatory antimicrobials are of total antimicrobial and therefore the concentration of each antimicrobial in these trials are half of the total concentration of antimicrobials. Detectable MICs were observed for the combination of antimicrobials against both separate cultures and the co-cultures. The C2ZNPs was effective against E. coli and E. faecium alone with an MIC of 0.024mg/mL and 12.5 mg/mL, respectively.



These trials give evidence for a synergistic property between the two antimicrobials as trials showed effective inhibition of E.coli, E. faceium, and the co-culture as compared to the trials using just one antimicrobial, which were not detected (>5%). The MIC of C1ZNP against E. faecium was a fourth of the MIC of zinc oxide against E. faecium. The MIC of the combined antimicrobial C1ZNPs and C2ZNPs in the co-culture was twice that of the MIC needed against the separate cultures. These values give evidence that these MRF strains increase their resistance to combined chitosan and Zinc oxide when in the same culture. This gives evidence that the molecular weight of chitosan can greatly alter the effectiveness of the antimicrobial. Further tests can confirm the optimal molecular weight for this antimicrobial against a particular strain.



This report assessed the potential for remediation of multi-drug resistant bacteria of two different nanoparticles, such as the chitosan and the ZnO. Although both of these have been evaluated previously either individually or in combination for their anti-bacterial properties, hitherto neither of these have been examined for potential for remediation of the multi-drug resistant bacteria.



Since the association between the molecular weight of chitosan and its anti-bacterial property has been controversial [32] and this has not been studied for MRF and VRE strains, we initiated our investigations using two different chitosan nnaoparticles, one oligomeric chitosan (3kDA) nanoparticles and a high molecular weight (50kDA) chitosan. Chitosan presents distinct mechanisms according to whether a bacteria is gram-positive or gram-negative; in previous studies, electron micrographs for S. aureus and E. coli interacting with chitosan show how the cell membrane of S. aureus was “weakened or even broken, while the cytoplasm of E. coli was concentrated and the interstice of the cell were clearly enlarged” [7], which provides ample evidence to suggest two main antibacterial mechanisms performed by chitosan. For Gram-positive bacteria, chitosan forms a polymer membrane around the cell’s surface preventing any nutrients from entering while for Gram-bacteria, chitosan with lower molecular weight entered the cell through pervasion [6]. Chitosan seems to work more efficient against gram-negative bacteria due to how its positively-charged structure adsorbs the electronegative substance in the cell and flocculate it to disturb the physiological activities of the bacteria and inhibit it. However, chitosan is naturally a large molecule, therefore the use of chitosan oligomers present a stronger choice if the molecules would be combined with another compound for a synergistic effect. Although chitosan oligomers do not have the same level of antibacterial activity as chitosan, their smaller size allows for a lower molecular weight and the facilitation of penetrating the bacterial surface. The effect of this property is seen as chitosan oligomers seemed to have an increased antibacterial activity against gram-negative bacteria at lower molecular weight such as 1 kDa, where Kyoon No et al., 2002 found that the growth of E. coli was reduced by 1 to 3 log cycles at a 1.0% concentration of chitosan oligomer with various degrees of polymerization [8]. Moreover, the ZnO nanoparticle effect is more pronounced “against Gram-positive bacterial than gram-negative bacterial strains” [9]. Gram-positive bacteria have a thick layer of peptidoglycan polymer that encircles the cell and a much thicker cell wall, while gram-negative have two thin cell membranes divided into an outer membrane and a plasma membrane [2], therefore they both require different agents against their different structures. Chitosan oligomers’ polysaccharide structure not only contain transcellular properties to cross cellular membranes, they also contain mucoadhesive and bioadhesive properties that contribute to their absorption improving effects [10] The positively-charged chitosan does not only bind to negatively-charged oxides, it also can bind to different drugs or peptide hormones like calcitonin to deliver a specific dose effectively partly due to its bioadhesive properties with gram-negative bacterial membranes or negative mucus in tissue membrane in the case of calcitonin delivery [10]. Since chitosan has the structural ability to bond to metal oxide compounds such as the ionic ZnO, a possibility exists to develop an antimicrobial agent that can efficiently work against both types of bacteria by bonding these two compounds in order to create a synergistic combination that targets a broader range of bacteria found in food products without risking human health.



The applicability of ZnO as an antimicrobial agent is due to its morphology that broadens the uses of it against various bacteria. The compound’s structure allows for an easier biocompatibility over other metal oxides, solubility in alkaline medium, and the Zn–O terminated polar surfaces [3]. Zinc oxide nanoparticles seem to inhibit or cause bacterial death more efficiently when they are smaller in size but higher in concentration. A smaller size at higher concentrations provides higher specific surface areas and facilitates the penetration of the antimicrobial agent into the bacterial membrane [5]. Virtually every unique property of ZnO proves to be beneficial in regards to antibacterial activity. Although ZnO is usually insoluble in water due to its high polarity, it can be managed efficiently in an aqueous cell culture media such as tryptic soy broth, also known as TSB. Zinc oxide possesses photo-oxidizing and photocatalysis impacts on chemical and biological species [2], which combined with its bio-safe composition, provides a safe interaction on food products where they come in contact with bacteria to inhibit and/or kill it to prevent food-related diseases.



Additionally, this study adds a novel perspective on the increased effectiveness of chitosan by molecular weight when in the presence of ZnO. While the oligomer of chitosan (3kDA) in literature shows the least potential as a possible effective antimicrobial, the effectiveness of chitosan oligomers against MRFs was substantially amplified by the addition of ZnO. The discrepancy between our data and the current literature may be due to the presence of ZnO along with the structural modifications of the chitosan oligomers used to generate optimal conditions.



Combination of chitosan oligomers with ZnO demonstrated synergistic effects in remediation of important food-borne bacteria including the resistant strains. Current literature has shown the synergistic antimicrobial properties of chitosan and ZnO [30], as well as detailed the synergistic properties of chitosan and ZnO individually against wild type bacteria [31]. However, there has been no quantitative data thus far on the precise concerted effect of these nanoparticles against multi-drug resistant microbes. This experiment has demonstrated the effect against both multi-drug resistant Gram positive and Gram negative fecal bacteria while comparing the combinatory antimicrobial properties to the individual nanoparticles. The overall objective of this experiment was to ascertain the efficacy of CZNPs synergism on co-cultured MRF strains through validated MIC tests and TEM assays. Specific goal was to validate a nanotherapeutic agent to further in situ intervention.



This research study has novelty demonstrated this success of CZNPs against both multi-drug resistant Gram positive and Gram negative fecal bacteria while comparing the combinatory antimicrobial properties to the individual nanoparticles. Synergism of CZNPs primarily C1ZNPs proved to be successfully suppressive to MRFs over WT strains. It is concluded that C1ZNPs has therapeutic potential to in situ intervention.



Acknowledgements



The Research, Innovation & Economic Development of USF is thankfully acknowledged for its grant support to this research study. The authors also thank the Department of Integrative Biology at USF for providing their TEM core facility access and service. The College of Pharmacy is also genuinely recognized for its assistance in nanotechnology.



1. Bakhshi S, Padmanjali KS, Arya LS (2008) Infections in childhood acute lymphoblastic leukemia: an analysis of 222 febrile neutropenic episodes. Pediatr Hematol Oncol 25: 385-392.
2. Cattaneo C, Quaresmini G, Casari S, Capucci MA, Micheletti M, et al., (2008) Recent changes in bacterial epidemiology and the emergence of fluoroquinolone-resistant Escherichia coli among patients with haematological malignancies: results of a prospective study on 823 patients at a single institution. J Antimicrob Chemother 61: 721-728.
3. Krcmery V, Spanik S, Mrazova M, Trupl J, Grausova S, et al., (2002) Bacteremias caused by Escherichia coli in cancer patients - analysis of 65 episodes. Int J Infect Dis 6: 69-73.
4. Limayem A, Donofrio RS, Zhang C, Haller E, Johnson MG (2015) Studies on the drug resistance profile of Enterococcus faecium distributed from poultry retailers to hospitals, Journal of environmental science and health Part B Pesticides food contaminants and agricultural wastes. Accepted.
5. Centers for Disease Control and Prevention (CDC), (2013) Antibiotic Resistance Threats in the United States, 2013.
6. Lebreton F, van Schaik W, Manson McGuire A, Godfrey P, Griggs A, et al., (2013) Emergence of Epidemic Multidrug-Resistant Enterococcus faecium from Animal and Commensal Strains. mBio vol. 4 no. 4 e00534-13.
7. Eisenstein BI, Jones GW, (1988) The spectrum of infections and pathogenic mechanisms of Escherichia coli. Adv Intern Med 33: 231-252.
8. Johnson JR, Russo TA (2002) Extraintestinal pathogenic Escherichia coli: "the other bad E coli". J Lab Clin Med 139: 155-162.
9. Orskov I, Orskov F (1985) Escherichia coli in extra-intestinal infections. J Hyg (Lond) 95: 551-575.
10. Johnson JR (1991) Virulence factors in Escherichia coli urinary tract infection. Clin Microbiol Rev 4: 80-128.
11. Johnson JR, Kuskowski MA, Gajewski A, Sahm DF, Karlowsky JA (2004) Virulence characteristics and phylogenetic background of multidrug-resistant and antimicrobial-susceptible clinical isolates of Escherichia coli from across the United States, 2000-2001. J Infect Dis 190: 1739-1744.
12. Johnson JR, Stell AL (2000) Extended virulence genotypes of Escherichia coli strains from patients with urosepsis in relation to phylogeny and host compromise. J Infect Dis 181: 261-272.
13. Franz CM, Huch M, Abriouel H, Holzapfel W, Gálvez A (2011) Enterococci as probiotics and their implications in food safety. Int J Food Microbiol 151: 125-140.
14. Werner G, Klare I, Heier H, Hinz KH, Bohme G, Wendt M, and Witte W (2000) Quinupristin/dalfopristin-resistant enterococci of the satA (vatD) and satG (vatE) genotypes from different ecological origins in Germany. Microb Drug Resist 6: 37-47.
15. Arias CA and Murray BE (2012) The rise of the Enterococcus: beyond vancomycin resistance. Nat Rev Microbiol 10: 266-278.
16. Limayem A (2015) The mutating gastrointestinal flora, multidrug resistant Enterococcus faecium, Agriculture, Food and Analytical Bacteriology. Accepted.
17. Laukova A, Chrastinova L, Placha I, Strompfova V, Szabóova R, et al., (2012) Beneficial effect of bacteriocin-producing strain Enterococcus faecium EF 55 of non rabbit origin in rabbits. In: Hacklander, K. and Thurner, C. Ed. BOKU-Reports on wildlife research and game management. Proc 4th World Lagomorph Conference, Vienna, Austria, Vienna, p. 77.
18. De Kwaadsteniet M, Todorov SD, Knoetze H, Dicks LM (2005),Characterization of a 3944 Da bacteriocin, produced by Enterococcus mundtii ST15, with activity against Gram-positive and Gram-negative bacteria. Int. J. Food Microbiol. 105:433-444.
19. Leroy F, Foulquie MR, Vuyst LD (2003) Enterococcus faecium RZS C5, an interesting bacteriocin producer to be used as a co-culture in food fermentation. Int. J. Food Microbiol. 88:235-240.
20. Lund B, Edlund C (2001) Probiotic Enterococcus faecium strain is a possible recipient of the vanA gene cluster. Clin. Infect. Dis. 32:1384-1385.
21. Fisher K, Phillips C (2009) The ecology, epidemiology and virulence of Enterococcus. Microbiol. 155:1749–1757.
22. Sahoo SK, Parveen S, Panda JJ  (2007) The present and future of nanotechnology in human health care. Nanomedicine 3:20-31.
23. Arias CA, Murray BE (2009) Antibiotic-resistant bugs in the 21st century—a clinical super-challenge. N Engl J Med 360:439-443.
24. Paul S, Seema NP (2015) In vitro antibacterial potential of chitosan and its derivatives on pathogenic enterobacteriaceae. Natl J Physiol Pharm Pharmacol 5:119-124.
25. Reddy KM, Feris K, Bell J, Wingett DG, Hanley C, Punnoose A (2007) Selective toxicity of zinc oxide nanoparticles to prokaryotic and eukaryotic systems. Appl Phys Lett 90:2139021-2139023.
26. Jin T, Sun D, Su JY, Zhang H, Sue HJ (2009) Antimicrobial efficacy of zinc oxide quantum dots against Listeria monocytogenes, Salmonella Enteritidis, and Escherichia coli O157:H7. J Food Sci 74:M46-52.
27. Dixit S et al., (2013) Phospholipid micelle encapsulated gadolinium oxide nanoparticles for imaging and gene delivery. RSC Adv 3:2727–2735.
28. Kumar A, Glaum M, El-Badri N, Mohapatra S, Haller E (2011) Initial observations of cell-mediated drug delivery to the deep lung. Cell Transplant 20:609-618.
29. Premanathan M, Karthikeyan K, Jeyasubramanian K, Manivannan G (2011) Selective toxicity of ZnO nanoparticles toward Gram-positive bacteria and cancer cells by apoptosis through lipid peroxidation. Nanomedicine. 7:184-92.
30. Elhady MM (2012) Preparation and characterization of chitosan/zinc oxide nanoparticles for imparting antimicrobial and UV protection to cotton fabric. International journal of carbohydrate chemistry, 6.
31. Perelshtein I, Ruderman E, Perkas N, Tzanov T, Beddow J, Joyce E, Gedanken, A (2013) Chitosan and chitosan–ZnO-based complex nanoparticles: formation, characterization, and antibacterial activity. J Mater Chem B 1:1968-1976.
32. No HK, Park NY, Lee SH, Meyers SP (2002) Antibacterial activity of chitosans and chitosan oligomers with different molecular weights. Int J Food Microbiol 74:65-72.
